Aluminum sheets

5052 Aluminum Sheet

  • Alloy5052
  • TemperO / H22 / H24 / H26 / H28 / H32 / H34 / H36 / H38
  • Thickness0.15-600mm
  • Width20-2600mm
  • Port of LoadingQingDao,China
  • CertificatedISO9001
Email

5052 ALUMINUM SHEET SUMMARY:

5052 Aluminum Sheet in H32 temper has very good corrosion resistance to seawater and marine and industrial atmosphere. It also has very good weldability and good cold formability. It is a medium to high strength alloy with a strength slightly higher than 5251 and a medium to high fatigue strength.

5052 ALUMINUM SHEET FEATURES:

5052 aluminum alloy is light in weight, nonmagnetic and non-heat treatable. It has good workability and high fatigue strength with good resistance to correction even in salt water. Besides, it can be anodized to improve correction resistance of the material in corrosive environment. So 5052 aluminum sheet is high suitable for marine applications.

5052 ALUMINUM SHEET CHEMICAL COMPOSITION:

ElementsSiFeCuMnMgCrZnTiOthersAl
Content0.250.40.10.12.2-2.80.15-0.350.1-0.15Remain

5052 ALUMINUM SHEET MECHANICAL PROPERTIES:

Alloy
Temper
Specified thicknessTensile
strength
Yield
strength
Elongation
(MPa)(MPa)(%)
5052 HO/H1110.3~0.63mm173-213min66min 15
0.63~1.2mmmin 17
1.2~6.3mmmin 19
6.3~50mmmin 18
5052/H32 or 5052 H220.4~0.63mm214-262min159min 4
0.63~1.2mmmin 5
1.2~6.3mmmin 7
6.3~50mmmin 11
5052/H34 or 5052 H240.4~0.63mm235-282min180min 3
0.63~1.2mmmin 4
1.2~6.3mmmin 6
6.3~50mmmin 10
5052/H36 or 5052 H260.1~0.32mm256-303min200min 2
0.32~0.63mmmin 3
0.63~4mmmin 4
5052/H38 or 5052 H280.15~0.32mmmin269min221min 2
0.32~0.63mmmin 3
0.63~3.2mmmin 4

5052 ALUMINUM SHEET APPLICATIONS:

5052 aluminum sheet is used for marine, chemical and petrochemical equipment and components.

Treadplate

Boilermaking

Containers

Nameplates

Road Signs

Architectural Paneling

Welded Tubes

Chemical Industry

Irrigation

Desalination units

Pressure Vessels

Rivets

RELEVANT GRADE OF 5052 ALUMINUM SHEET

Relevant grade of 3004 Aluminum Sheet

5052 ALUMINUM SHEET PACKING:

5052 Aluminum Sheet of packaging meet the export standard. Plastic film and brown paper can be covered at customers’ need. wooden case or wooden pallet is adopted to protect products from damage during the delivery.

As a China-based 5052 aluminum sheet manufacturer and supplier, we at Haomei also produce aluminum slit coil, aluminum strip, coated aluminum coil, aluminum plate, anodising aluminum sheet, embossed aluminum sheet, etc. For more detailed information, please continue browsing our website or feel free to contact us directly.
